Huahuan_Products_SDWAN

Products Guide

SDWAN Product

SD-WAN is one of the cloud-managed functions of the Huahuan Cloud Service (ACS), a cloud-based management and orchestration platform that makes the networkinfrastructure of a distributed enterprise cloud manageable and programmable.Besides SD-WAN, the platform’s cloud-managed functions include

Wifi, Routing,NAT, Firewall, NAC, and ITSM. All these functions can be orchestrated from the cloud at any remote site or branch of a distributed enterprise. With zero touch provisioning supported, they work together to digitize and automate branchoperations by constructing a

performance assured network infrastructure that connects employees, branches, HQ, DCs, and the cloud, all while ensuring highsecurity, deep visibility, and 100% centralized programmability.

Software Features

Multicast	IGMP V1/V2/V3, IGMP-Snooping V1/V2/V3
MPLS	LDP, MPLS L3 VPN, Static LSP, Dynamic LSP
WAN Link selection	Dynamic transport path selection based continuous monitoring of latency, jitter and packet loss of each WAN link
Flow-based load balancing	Support sending different applications on different WAN links based their priority and SLA
Packet-based load balancing	Support link aggregation, tunnel binding, data reorganization
Unidirectional measurement	Support unidirectional traffic measurement, continuous measurement on each packet
Application-aware	Support application detection with DPI and selecting transport path or path aggregation and the balancing algorithms based the application’s SLA
VPN	GRE VPN, L2TP VPN, MPLS VPN
QOS	Role-based prioritization and bandwidth control, application-based prioritization and bandwidth control, traffic shaping
LTE	FDD LTE, TDD LTE (Currently only VSM810-L supports）
NAC	Role-based NAC, Black / White list,
WiFi AC	AP management, CAPWAP, User management, RF management, QoS, WLAN security(WEP/WPA/WPA2 /WPA3)
Authentication	Radius, AD, LDAP MAC address based authentication 802.1X authentication Social media authentication (Facebook, WeChat, etc.) SMS authentication Customer’s APP authentication
Firewall/NAT	Stateful firewall, SNAT/DNAT
Topology	Mesh, Hub-Spoke
Virtualization deployment	Supports VMWare, Virtualbox, KVM
programmability	Restful API
Report	Reports of system, interfaces, users, applications, traffic, and quality of WAN links
Maintenance	Support Web, Console, SSH management
Basic functions	ARP, DHCP Server/Client/Relay, PPPOE Client, NAT, VLAN
LA	IEEE 802.1P, IEEE802.1Q, IEEE802.3, MSTP
IPv4 routing	Policy routing, Static routing, OSPF, BGP
IPv6 routing	IPv6 ND, IP6v6 PMTU, IPv6 FIB
